ABR42 High-Performance Gearbox with IP65 Protection

The ABR42 gearbox is a high-performance component designed to deliver exceptional torque and efficiency for a variety of applications. With a nominal torque rating that ensures reliability and a maximum output torque capable of handling demanding tasks, this gearbox is ideal for use in industrial machinery, robotics, and automation systems.

Operating at a rated input speed of 3000 RPM, the ABR42 can handle a maximum input speed of up to 6000 RPM, making it versatile for high-speed applications. Its design includes a maximum radial force of 280 N and a maximum axial force of 200 N at a speed of 100 RPM, ensuring robust performance under significant loads. The gearbox also features permanent lubrication, which simplifies maintenance and enhances longevity, allowing it to function effectively in a variety of environments.

Efficiency is a key consideration in the design of the ABR42, with a maximum efficiency rating of 90%. This high efficiency not only reduces energy consumption but also minimizes heat generation during operation, contributing to the gearbox's extended lifespan. Operating within a temperature range of -25°C to +90°C, it is suitable for diverse environmental conditions.

The ABR42 is designed for arbitrary installation methods, offering flexibility in integration into existing systems. With a weight of just 0.7 kg, it is lightweight yet robust, facilitating easy handling and installation. The average lifespan of this gearbox is approximately 20,000 hours, making it a reliable choice for long-term use.

Protected with an IP65 rating, the ABR42 is designed to resist dust and moisture ingress, ensuring reliable operation even in harsh conditions. The flange accuracy adheres to DIN 42955-R standards, ensuring precise alignment and performance.

With a standard backlash and precise backlash options, the gearbox can be customized to meet specific application requirements. The key standard is a round common flat key (A) as per GB1096-79, and it meets gear precision grade 6 according to GB/T10095-2008, ensuring high-quality performance.

In conclusion, the ABR42 gearbox offers an ideal combination of performance, efficiency, and durability for those seeking a reliable solution for their machinery and automation needs. Enhance your systems with the ABR42 and experience the benefits of precision engineering and high torque capabilities.
