KST-14D16-ZK-0001 1.8° Stepper Motor, 0.21A Rated Current, 4.2mH Inductance, 20g, 5.8N Thrust, 14mm Frame Size

The KST-14D16-ZK-0001 is an ultra-compact 24V DC stepper motor designed for space-constrained applications requiring low current consumption and precision motion control. With a 1.8° step angle, this motor offers precise and reliable movement in applications where size, power efficiency, and accuracy are key.

Featuring a rated current of 0.21A, resistance of 22Ω, and inductance of 4.2mH, the motor operates efficiently in low-power environments while maintaining smooth motion. The holding torque and thrust capabilities, along with its lightweight design (weighing only 20g), make it ideal for use in compact automation, robotics, and micro-motor applications.

With a rotor inertia of 0.8g·cm², the motor is highly responsive, allowing for minimal vibration and quick starts/stops. The shaft diameter of 4mm and motor length of 30.1mm make it a perfect fit for smaller, space-constrained devices. This motor’s low thrust of 5.8N ensures its suitability for delicate or lightweight systems.

Its insulation resistance of 100MΩ ensures high durability and safe operation in a variety of environments. The KST-14D16-ZK-0001 is an excellent choice for applications requiring precise control, compactness, and energy efficiency.
