High-Precision XXY Alignment Platform YK-XXY200170P-5-32105.png

High-Precision XXY Alignment Platform YK-XXY200170P-5-32105

2000×1700mm XXY platform with ±3μm repeatability, ±6° rotation, and 3000kgf load capacity for precise positioning.

    Contact us
    Detail description
    Technical parameter
    The YK-XXY200170P-5-32105 is a high-precision large-format alignment platform with a generous working area of 2000×1700mm. Engineered for demanding industrial environments, it offers ±3μm repeatability, ±90mm stroke, and ±6° rotation, ideal for applications requiring submicron-level accuracy. Built from anodized aluminum alloy and supported by a crossed roller guide, the platform delivers exceptional rigidity and flatness (0.5mm) while maintaining high load capacity (3000kgf horizontal). Driven by the AZM98AC-HS50 motor and Oriental 5-phase driver, and equipped with a Meiji SL-205NA-W sensor, this platform ensures stable, repeatable motion for critical positioning tasks.

    ●Motor configuration and performance parameters

    Product model

    YK-XXY200170P-5-32105

    Specification/mm

    2000*1700

    Height/mm

    330

    Repeat positioning accuracy/um

    ±3

    Stroke/mm

    ±90

    Rotation angle

    ±6°

    Screw diameter/mm

    φ32

    Screw lead/mm

    10

    Linear track

    Cross roller

    Flatness mm

    0.5

    Parallelism mm

    0.2

    Horizontal load kgf

    3000kgf

    Material

    Aluminum Alloy

    Surface treatment

    Anodic Black

    Main weight

    2400±2%

    Motor model

    AZM98AC-HS50

    Driver model

    Oriental five-phase drive

    Sensor

    SL-205NA-W（Meiji）
    sizeogl
